HMS-600&700&800&900&1000-2T

With the output power up to 1000 VA, Hoymiles new microinverter HMS-1000 series rank among the highest for 2-in-1 microinverters.

Each microinverter can connect up to 2 panels, with independent MPPT and monitoring maximizing the power production of your installation.

The new Sub-1G wireless solution enables more stable communication with Hoymiles gateway DTU.


Contact Us
Download Spec Sheet
1/4
  • Features
  • Tech Specs

Features

    • High-powered microinverter for 2-in-1 with output power up to 1000 VA.

    • With Reactive Power Control, compliant with EN 50549-1:2019, VDE-AR-N 4105:2018, VFR2019, etc.

    • Safer for rooftop solar stations with rapid shutdown compliance and isolated transformer.

    • Independent MPPT and monitoring ensure greater energy harvest and easier maintenance.

    • 2-in-1 design enables faster installation.

    • Sub-1G wireless solution allows stable communication in commercial and industrial settings.

Tech Specs

  • 600W
  • 700W
  • 800W
  • 900W
  • 1000W
    • Commonly used module power (W):
      240 to 405+
    • Maximum input voltage (V):
      60
    • Maximum input current (A):
      2 × 11.5
    • Number of MPPTs:
      1
    • Rated output power (VA):
      600
    • Nominal output voltage/range (V)* :
      230/180-275
    • CEC peak efficiency:
      96.70%
    • Commonly used module power (W):
      280 to 470+
    • Maximum input voltage (V):
      60
    • Maximum input current (A):
      2 × 11.5
    • Number of MPPTs:
      1
    • Rated output power (VA):
      700
    • Nominal output voltage/range (V)* :
      230/180-275
    • CEC peak efficiency:
      96.70%
    • Commonly used module power (W):
      320 to 540+
    • Maximum input voltage (V):
      65
    • Maximum input current (A):
      2 × 12.5
    • Number of MPPTs:
      1
    • Rated output power (VA):
      800
    • Nominal output voltage/range (V)* :
      230/180-275
    • CEC peak efficiency:
      96.70%
    • Commonly used module power (W):
      360 to 600+
    • Maximum input voltage (V):
      65
    • Maximum input current (A):
      2 × 13.3
    • Number of MPPTs:
      1
    • Rated output power (VA):
      900
    • Nominal output voltage/range (V)* :
      230/180-275
    • CEC peak efficiency:
      96.50%
    • Commonly used module power (W):
      400 to 670+
    • Maximum input voltage (V):
      65
    • Maximum input current (A):
      2 × 14
    • Number of MPPTs:
      1
    • Rated output power (VA):
      1000
    • Nominal output voltage/range (V)* :
      230/180-275
    • CEC peak efficiency:
      96.50%
