HMS-300&350&400&450&500-1T

Hoymiles’s new photovoltaic microinverter HMS-500-1T series is connected to one panel and is flexible for various applications.

All of the Hoymiles HMS-500-1T series are equipped with reactive power control and can meet the requirements of EN 50549-1:2019, VDE-AR-N 4105:2018, VFR2019, etc.

HMS-500-1T series with the new Sub-1G wireless solution enables more stable communication under various environmental conditions.

Download Spec Sheet

1/4

Features
Tech Specs

Features

- High-powered microinverter for 1-in-1 with output power up to 500 VA.
- With Reactive Power Control, compliant with EN 50549-1:2019, VDE-AR-N 4105:2018, VFR2019, etc.
- Safer for rooftop solar stations with rapid shutdown compliance and isolated transformer.
- Connected to one panel, flexible for various applications.
- Sub-1G wireless solution allows stable communication with Hoymiles gateway DTU.

Tech Specs

300W
350W
400W
450W
500W

- Commonly used module power (W):

  240 to 405+
- Maximum input voltage (V):

  60
- Maximum input current (A):

  11.5
- Number of MPPTs:

  1
- Rated output power (VA):

  300
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.70%
- Commonly used module power (W):

  280 to 470+
- Maximum input voltage (V):

  60
- Maximum input current (A):

  11.5
- Number of MPPTs:

  1
- Rated output power (VA):

  350
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.70%
- Commonly used module power (W):

  320 to 540+
- Maximum input voltage (V):

  65
- Maximum input current (A):

  12.5
- Number of MPPTs:

  1
- Rated output power (VA):

  400
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.70%
- Commonly used module power (W):

  360 to 600+
- Maximum input voltage (V):

  65
- Maximum input current (A):

  13.3
- Number of MPPTs:

  1
- Rated output power (VA):

  450
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.50%
- Commonly used module power (W):

  400 to 670+
- Maximum input voltage (V):

  65
- Maximum input current (A):

  14
- Number of MPPTs:

  1
- Rated output power (VA):

  500
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.50%
