PLUG ANYWHERE,
SAFETY EVERYWHERE

Plug-in Home Battery

  • 4–16kWh Capacity
  • 8,000 Life Cycles
  • 2500W Inverter
HiBattery 4020 AC

Freedom to Install Anywhere

HiBattery AC plugs directly into a standard home outlet — no inverter wiring required. Install it wherever it fits your space, completely independent of your existing solar setup.

  • Garage
  • Basement
  • Living Room

Turn Energy into Earnings

  • <2 Years
    Payback Period
  • 584 €
    Max.saving per year
  • Solar + HiBattery AC
    € 870
  • Solar Only
    € 286

With a setup of HiBattery 4020 X and four 500W PV modules, the system generates about 2,378 kWh of solar energy per year (=5.96 kWh/day). Around 30% is used directly during the day, while the surplus is stored in the battery and used at night achieving up to 90% self-consumption. At an electricity price of €0.4/kWh, this results in an estimated annual saving of about €584,maximizing the value of every kWh generated.

**Actual results may vary based on usage patterns, regional tariffs, and dynamic pricing conditions.

Hoymiles AI-EMS
Smarter AI, Greater Savings

Take control of your energy automatically and see your daily electricity costs.
Designed for Europe's 15-minute dynamic pricing, our AI-EMS recalculates every 3 hours ( 8× daily vs.
conventional once-daily systems) with latest weather forecasts and your usage data to deliver smarter decisions and higher accuracy.

Safety,
Engineered Beyond Industry Standards

Cell-Level Safety

Safety starts at the core — combining the proven stability of LFP prismatic cells, the high energy density and cost efficiency of 314Ah large-format design, and the next-generation protection of semi-solid-state electrolytes to power today’s needs and tomorrow’s innovations.

Intelligent BMS Protection

With 48-layer protection, 20% extended lifespan via active balancing, and intelligent all-climate control.

  • BMS Protection

    BMS Protection

    48 layers of BMS protection to prevent thermal runaway and fire risks

  • Cell Balancing

    Cell Balancing

    Intelligent cell balancing extending cycle life by up to 20%

  • Self-Heating

    Self-Heating

    Smart battery heating for reliable low-temperature operation

  • Dual-MCU

    Dual-MCU

    Dual-MCU Architecture feature independent overcharge/over-discharge protection

Fire Safety System

  • PV Input Overheat Protection
  • Internal Fire Extinguisher
  • Pressure Relief Valve
  • Stack Connector Thermal Monitoring

System-Level Safeguards

  • With premium cells and robust protection, HiBattery X ensures reliable, safe operation in any climate—designed to power you for years to come
    IP66

    Waterproof
    Dustproof

  • Each battery comes with an independent bidirectional DC/DC module. When a faulty battery is replaced or a new one is added, the system automatically balances the SOC, cutting pre-charging time and lowering expansion costs.

    Pack-Level
    DC/DC Balancing

  • 4020_img15(1).jpg

Power for Every Situation

Designed to optimize daily savings, protect your home during outages, and enable complete energy independence.

  • 4020_img19-en.jpg
  • EN(1).jpg

    Automatic switch-over keeps running whenever the grid goes down

  • 4020_AC_img17.jpg

    Connect with solar panels to create a fully self-sustaining energy system Ideal for cabins, holiday homes, boats, RVs, and remote properties.

  • Flexible Energy Modes
  • Home Backup
  • Off-Grid Living

Fully Certified. Fully Compliant.

  • VDE-AR-N 4105

  • IEC 62109-1 / -2

  • IEC 62619

  • EN 300 328

  • EN 301 489-1/17

  • EN 62311

  • EN 18031

  • EN 61000-6-x

  • IEC 62920

  • RoHS 2.0

  • REACH / SVHC

Built for Total Compatibility

  • 4020_img20_EN.jpg

    Zero Export Control

    Works with Hoymiles smart meters and third-party meters like Shelly, Ecotracker, and Linky via local LAN for faster response and precise zero export control.

  • Upgrad Your Existing Solar Setup

    No extra cabling or complex setup required. Instantly upgrade to storage for a more efficient and intelligent solar system.

  • Open MQTT

    unlocks endless smart automation possibilities—integrate with Home Assistant and more. After setup, disable the cloud for complete local control and total privacy.

Plug & Play

  • 01

    Stackable Module

  • 02

    Plug into a Standard Socket

  • 03

    Power On with One Tap

Find Your Perfect Fit

  • 1-2 Persons

    800-2000W Balcony System
    • ①
      HiBattery 4020 AC
    • Annual usage
      1000-2000kWh
    • Max.saving per year
      €584

  • 3-4 Persons

    6kW Existing Rooftop System
    • ①
      HiBattery 4020 AC
    • ②
      Expansion Battery
    • Annual usage
      5000-6600kWh
    • Max.saving per year
      €1752

  • 4+ Persons

    10kW Rooftop System
    • ①
      HiBattery 4020 AC
    • ③
      Expansion Battery
    • Annual usage
      9000-11000kWh
    • Max.saving per year
      €2336

  • Essential Living

  • Smart Family Living

  • Full Home Independence

  • ldeal for studio flats or 1-2 person households. Keeps your fridge, lighting, phone charging, and Wi-Fi running through the night — a reliable backup for everyday outages or off-peak energy savings

  • Designed for families of 3-4 in a semi-detached or larger home. With 12 kWh of capacity, it can handle an induction hob (used wisely), run a washing machine cycle. and power a full home office-seamlessly integrating with rooftop solar to cut your energy bills further.

  • For larger homes or high-demand households ready to take control. With 16 kWh of storage, it supports heat pump cycles, overnight EV top-up charging, and multiple heavy appliances -built for a life less dependent on the grid, fully compatible with a solar-first lifestlye.

Key Specs

  • 4020 Wh
    Capacity
  • 15 Years
    Product Lifespan
  • 10 Years
    Warranty
  • 16.08 Wh
    Expandable Capacity
  • 800 VA
    On-Grid Ac output
  • Bluetooth, Wi-Fi (2.4GHz)
    Wireless Connection
  • 2500
    Maximum output power
  • LFP 8000 cycles
    Battery Chemistry
  • 520 * 199 * 203 mm
    Dimensions (Lx W x H)
  • -20 to 55 °C
    Operating temperature range
