HMS-300&350&400&450&500W-1T

Hoymiles HMS-500W series microinverters are specifically designed for mini solar systems in open spaces like balconies, Hoymiles HMS-500W series microinverters feature integrated industrial+grade Wi-Fi module. Their output power reaches up to 500 VA.

With the user-friendly HMS Plug and Play Cable, installation is effortless for users of all levels. Users can connect the microinverter directly to a socket—no complex wiring is required.

Additionally, system monitoring is simplified for the HMS-500W series with two convenient options: real-time monitoring via Direct Connection and remote control through the S-Miles Cloud platform.

Download Spec Sheet

1/4

Learn More

Features
Tech Specs

Features

- Built-in industrial+ grade Wi-Fi module for high reliability.
- Enhanced safety with rapid shutdown compliance and isolated transformer.
- 1-in-1 design to suit versatile installation scenarios.
- Output power setting function to customize performance.
- Two options for monitoring and management: Direct Connection and S-Miles Cloud.
- Plug-and-play design for balcony solar systems.

Tech Specs

400W
500W
450W
300W
350W

- Commonly used module power (W):

  320 to 540+
- Maximum input voltage (V):

  65
- Maximum input current (A):

  14
- Number of MPPTs:

  1
- Rated output power (VA):

  400
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.70%
- Commonly used module power (W):

  400 to 670+
- Maximum input voltage (V):

  65
- Maximum input current (A):

  16
- Number of MPPTs:

  1
- Rated output power (VA):

  500
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.50%
- Commonly used module power (W):

  360 to 600+
- Maximum input voltage (V):

  65
- Maximum input current (A):

  15
- Number of MPPTs:

  1
- Rated output power (VA):

  450
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.50%
- Commonly used module power (W):

  240 to 405+
- Maximum input voltage (V):

  60
- Maximum input current (A):

  12
- Number of MPPTs:

  1
- Rated output power (VA):

  300
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.70%
- Commonly used module power (W):

  280 to 470+
- Maximum input voltage (V):

  60
- Maximum input current (A):

  13
- Number of MPPTs:

  1
- Rated output power (VA):

  350
- Nominal output voltage/range (V)* :

  230/180-275
- CEC peak efficiency:

  96.70%
